LM339N SMD

Pin Name ?Description
1 1OUT Output pin of the comparator 1
2 2OUT Output pin of the comparator 2
3 VCC Power supply
4 2IN- Negative input pin of the comparator 2
5 2IN+ Positive input pin of the comparator 2
6 1IN- Negative input pin of the comparator 1
7 1IN+ Positive input pin of the comparator 1
8 3IN- Negative input pin of the comparator 3
9 3IN+ Positive input pin of the comparator 3
10 4IN- Negative input pin of the comparator 4
11 4IN+ Positive input pin of the comparator 4
12 GND Ground
13 4OUT Output pin of the comparator 4
14 3OUT Output pin of the comparator 3

Features and Electrical Characteristics of LM339

  • Four individually operated voltage comparators
  • Low noise interference among comparators
  • Single Supply Operation: +3.0 V to +36 V
  • Dual ?Supply Operation: +18V and -18V
  • Low Input Bias Current: 25 nA
  • Low Input Offset Current: ?5.0 nA
  • Low Input Offset Voltage
  • Input Common Mode Voltage Range to GND
  • Low Output Saturation Voltage: 130 mV @ 4.0 mA
  • TTL and CMOS compatible
  • ESD Clamps on the inputs increase reliability without affecting device operation
  • Pb?Free, Halogen Free/BFR Free and RoHS compliant
