Features:-
??Typical propagation delay: 12 ns
??3-STATE outputs for connection to system buses
??Wide power supply range: 2?6V
??Low quiescent supply current: 80 ?A (74 Series)
??Output current: 6 mA
Specifications:-
Parameter | Specification |
Supply Voltage (VCC | ? 0.5 to + 7.0V |
Input Voltage (VIN) | ??1.5V to VDD + 1.5V |
Output Voltage (VOUT) | ?? 0.5 to VCC + 0.5V |
Clamp Diode Current (IIK, IOK) | ? ?? 20 mA |
DC Output Current, per pin (IOUT) | ? 35 mA |
? ?DC VCC or GND Current, per pin (ICC) | ? 70 mA |
?Storage Temperature Range (TSTG) | ? 65?C to + 150?C |
Power Dissipation (PD) (Note 4) | ?600 mW |
S.O. Package only | ? 500 mW |
Lead Temperature (TL) (Soldering 10 seconds) | 260?C |
