Features
? 2.0 A Minimum Peak Output
Current
? 15 kV/?s Minimum Common
Mode Rejection (CMR) at
VCM = 1500 V
? 0.5 V Maximum Low Level
Output Voltage (VOL)
Eliminates Need for Negative
Gate Drive
? ICC = 5 mA Maximum Supply
Current
? Under Voltage Lock-Out
Protection (UVLO) with
Hysteresis
? Wide Operating VCC Range:
15 to 30 Volts
? 500 ns Maximum Switching
Speeds
? Industrial Temperature
Range: -40?C to 100?C
? Safety Approval
UL Recognized
2500 Vrms for 1 min. for
HCPL-3120
3750 Vrms for 1 min. for
HCPL-J312
5000 Vrms for 1 min. for
HCNW3120
Applications
? IGBT/MOSFET Gate Drive
? AC/Brushless DC Motor
Drives
? Industrial Inverters
? Switch Mode Power
Supplies
