| Product Dimensions | 7.12 x 6.5 mm | |
| Pin Count | 6 | |
| Output Type | DC | |
| Operating Temperature | -55 to 110 ?C | |
| Number of Channels per Chip | 1 | |
| Mounting | Through Hole | |
| Minimum Isolation Voltage | 5000 Vrms | |
| Maximum Rise Time | 10 us | |
| Maximum Power Dissipation | 200 mW | |
| Maximum Fall Time | 10 us | |
| Maximum Current Transfer Ratio @ Current | 80@10mA % | |
| Maximum Collector Emitter Voltage | 80 V | |
| Maximum Collector Emitter Saturation Voltage | 300 mV | |
| Maximum Collector Current | 50 mA | |
| Max Processing Temp | 260 | |
| Input Type | DC | |
| Input Current | 60 mA | |
| Channel Type | N |
