FZ1500R33HL3 MODULE

Product Description:

The FZ1500R33HL3 is a high-power IGBT module from Infineon, rated at 1500A and 3300V. Engineered for demanding industrial power conversion applications, it delivers exceptional performance with unbeatable robustness and high DC stability.

• Part Number: FZ1500R33HL3
• Manufacturer: Infineon
• Type: IGBT Module
• Current Rating: 1500A
• Voltage Rating: 3300V
• Operating Junction Temperature (Tvj op): 150°C
• Base Plate Material: AlSiC (Aluminium Silicon Carbide)
• Isolation: Isolated Base Plate
• CTI: > 600
• Short Circuit Capability: High / Self-Limiting
• Switching Losses: Low
• VCEsat: Low with Positive Temperature Coefficient
• DC Stability: High
