|Number of Outputs:||3||MPN:||
|High Side Voltage – Max (Bootstrap):||600V||Configuration:||3 Phase Bridge|
|Voltage – Supply:||10 V ~ 20 V||Input Type:||Inverting|
|Operating Temperature:||-40?C ~ 125?C||Delay Time:||675ns|
|Mounting Type:||Through Hole||Current – Peak:||200mA|
|Supplier Device Package:||28-DIP||Number of Configurations:||1|
Does not apply
90.00 AED – 180.00 AED
1PCS IR2130 IC DRIVER BRIDGE 3-PHASE 28-DIP 2130
pack of 10, pack of 5
36.00 AED – 120.00 AED
The SN65175 and SN75175 are monolithic quadruple differential line receivers with 3-state outputs. They are designed to meet the requirements of ANSI Standards EIA/TIA-422-B, RS-423-B, and RS-485, and several ITU recommendations. These standards are for balanced multipoint bus transmission at rates up to 10megabits per second. Each of the two pairs of receivers has a common active-high enable. The receivers feature high input impedance, input hysteresis for increased noise immunity, and input sensitivity of ?200 mV over a common-mode input voltage range of ?12 V. The SN65175 and SN75175 are designed for optimum performance when used with the SN75172 or SN75174 quadruple differential line drivers. The SN65175 is characterized for operation from -40?C to 85?C. The SN75175 is characterized for operation from 0?C to 70?C.
140.00 AED – 280.00 AED
The regulator contains a triple voltage regulator and a power switch. The IC includes a monitoring circuit to warn if a low voltage or no voltage condition is occuring. In stand-by output is active as long as possible even when in thermal shutdown or any other fault conditions.
