Transistor Polarity |
N |
Maximum Drain Source Voltage |
60 V |
Maximum Continuous Drain Current |
30 A |
Maximum Gate Source Voltage |
?20V |
Maximum Power Dissipation |
68 W |
Number of Elements per Chip |
1 |
Peak Forward Voltage |
60VDC |
Output Power |
88W |
Peak Non-Repetitive Surge Current |
120A |
Peak Reverse Current |
25uA |
Channel Mode |
N-Channel Enhancement |
Peak Reverse Recovery Time |
100ns |
Channel Type |
N |
Peak Reverse Repetitive Voltage |
60VDC |
Configuration |
Single |
Maximum Drain Source Resistance |
0.04?Ohms@10V |
Category |
Power MOSFET |
Maximum Continuous Forward Current |
30A |
Typical Fall Time |
40ns |
Typical Gate Charge @ Vgs |
34nC @10V |
Typical Input Capacitance @ Vds |
700pF@25V |
Typical Rise Time |
49ns |
Typical Turn-Off Delay Time |
31ns |
Typical Turn-On Delay Time |
7ns |
Minimum Operating Temperature |
-55?C |
Maximum Operating Temperature |
175?C |
Mounting |
Through Hole |
Packaging |
Bulk |
Pin_Count |
3 |
Family |
IRFZ34 |
Product Width |
4.69mm |
Product Height |
8.77mm |
Product Length |
10.54mm |
Product Type |
MOSFET |
