KSD 301 250V 10A SWITCH

Product description

It is close until the surface reaches 130 Celsius degree and then the switch open. Automatically reset when the surface cools off about 5 degrees, the switch automatically close. Opening-closing durability: 10000 times or more (under rated load).general-purpose low cost, compact, large capacity, minute current THERMOSTAT. This Ksd301 THERMOSTAT is used either as temperature control and safety limit for household electric appliances and widely applicable for coffee maker, water heater, immersion heaters, electric cookers, Microwave ovens, automatic toasters, etc.

Product details

Product Dimensions ‏ : ‎ 3.3 x 1.52 x 1.27 cm
Item Weight ‏ : ‎ 4.54 g
Item Dimensions LxWxH ‏ : ‎ 33 x 15 x 13 Millimeters
Included Components ‏ : ‎ 1

About this item

Product name : temperature control switch; model. No : Ksd301; action Type : normally close(nc)
Action temperature : 130C; Voltage : AC 250V; current : 10A
Insulation resistance : max. 100 mohm; size : 3.4 x 1.6 x 1.2Cm/1.3″ x 0.6 inch x 0.5″(L*d*h); mounting hole size : 4.4 x 3.5Mm/0.2″ x 0.1″(L*w)
Mounting hole center distance : 24Mm/0.9″; material : metal, plastic; color : Black, Silver tone
Net weight : 5G; Package Content : 1 x temperature control switch
