RM85-2011-35-1024-24VDC 8PIN PCB RELPOL RELAY

RM85-2011-35-1024 SPDT Miniature Relay 24V 16A PCB, Coil resistance : 1440 Ω Contacts: 2CO, 2NO; rated load AC1 – 16 A/250 V AC; coils AC or DC; for PCB and sockets.

Specifications

• Brand : RELPOL
• Model : RM85-2011-35-1024
• Product Type : Relay
• Contacts configuration : SPDT
• Rated coil voltage : 24V DC
• AC contacts rating : 16A / 250V AC
• DC contacts rating : 16A / 24V DC
• Constant Current : 16A
• Switched voltage : 250V AC, 440V AC
• Relay variant : Miniature
• Mounting Type : PCB
• Coil resistance : 1440 Ω
• Coil voltage : 16.8 to 30.6 V DC
• Operating temperature : -40 – +80°C
• Terminal pitch : 5mm
• Dimension : 29 x 12.7 x 15.7 mm
• Weight : 15g
