| Manufacturer | Sanken | |
|---|
| Series | – | |
|---|
| Packaging | Tube | |
|---|
| Part Status | Not For New Designs | |
|---|
| Output Configuration | Half Bridge (3) | |
|---|
| Applications | AC Motors | |
|---|
| Interface | Logic | |
|---|
| Load Type | Inductive | |
|---|
| Technology | IGBT | |
|---|
| Rds On (Typ) | – | |
|---|
| Current – Output / Channel | 20A | |
|---|
| Current – Peak Output | 30A | |
|---|
| Voltage – Supply | 13.5V ~ 16.5V | |
|---|
| Voltage – Load | 400V (Max) | |
|---|
| Operating Temperature | 125°C (TJ) | |
|---|
| Features | Auto Restart, Bootstrap Circuit | |
|---|
| Fault Protection | Current Limiting, Over Temperature, UVLO | |
|---|
| Mounting Type | Through Hole | |
|---|
| Package / Case | 33-PowerDIP (1.307″, 33.20mm) Exposed Pad | |
|---|
| Supplier Device Package | 33-PowerDIP LF2552 |
|---|
