SD6830 PWM PFM Power Management IC

SD6830 IC

SD6830 IC is current mode PWM+PFM controller with built-in high-voltage MOSFET used for SMPS.
It features low standby power and low start current. In standby mode, the circuit enters burst mode to reduce the standby power dissipation.
The switch frequency is 25~67KHz decided by the load with jitter frequency for low EMI.
Built-in peak current compensation circuit makes the limit peak current stable even with different input AC voltage.
Maximum peak current compensation during power-on reduces pressure on transformer to avoid saturation, the peak current compensation will decrease for balance after power-on.
Limit output current can be adjusted through the resistor connected to CS
Part Number: SD6830
Maker: Silan Microelectronics
Energy Star: Meets Energy Star 2.0 requirements
Start-up Current: Low start-up current (3 µA)
Built in Frequency Oscillator
Various switching frequency following load for the high efficiency
EMI Frequency jitter for low EMI
Overvoltage, primary winding overcurrent, overload and over
Temperature protections
External peak current sense resistor
Undervoltage lockout
Built-in high voltage MOSFET
Auto restart mode
Peak current compensation Maximum peak current
compensation for initialization to realize the soft start function.
Burst mode
Cycle by cycle current limit
