| Description | Texas Instruments SN7400N (quadruple 2-input NAND gate), in a 14-pin dual-in-line package, manufactured in 1976, week 45. This is the first member of the successful TTL logic family. |
|
TYPE
|
DESCRIPTION
|
SELECT
|
|---|---|---|
|
Category
|
|
|
|
Mfr
|
Texas Instruments
|
|
|
Series
|
|
|
|
Package
|
Tube
|
|
|
Part Status
|
Active
|
|
|
Logic Type
|
NAND Gate
|
|
|
Number of Inputs
|
2
|
|
|
Features
|
–
|
|
|
Voltage – Supply
|
4.75V ~ 5.25V
|
|
|
Current – Output High, Low
|
400?A, 16mA
|
|
|
Logic Level – Low
|
0.8V
|
|
|
Logic Level – High
|
2V
|
|
|
Max Propagation Delay @ V, Max CL
|
22ns @ 5V, 15pF
|
|
|
Operating Temperature
|
0?C ~ 70?C
|
|
|
Mounting Type
|
Through Hole
|
|
|
Supplier Device Package
|
14-PDIP
|
|
|
Package / Case
|
14-DIP (0.300″”, 7.62mm)
|
|
|
Number of Circuits
|
4
|
|
|
